OAuth2
OAuth2所涉及到的对象主要有以下四个:
- Client 第三方应用,我们的应用就是一个Client
- Resource Owner 资源所有者,即用户
- Authorization Server 授权服务器,即提供第三方登录服务的服务器,如Github
- Resource Server 拥有资源信息的服务器,通常和授权服务器属于同一应用
OAuth2的基本流程为:
- 第三方应用请求用户授权。
- 用户同意授权,并返回一个凭证(code)
- 第三方应用通过第二步的凭证(code)向授权服务器请求授权
- 授权服务器验证凭证(code)通过后,同意授权,并返回一个资源访问的凭证(Access Token)。
- 第三方应用通过第四步的凭证(Access Token)向资源服务器请求相关资源。
- 资源服务器验证凭证(Access Token)通过后,将第三方应用请求的资源返回。
Github对应用开放授权
进入github中的Settings/Developer settings中创建一个应用,表示你的应用会使用github授权。
填写好相关的信息后,填写Authorization callback URL
为http://localhost:8080/oauth/github/callback(后面授权会用到),可以得到Client ID 和 Client Secret,结果如下:
github授权第三方应用的过程
根据 GitHub 登录链接可以回调获得 code
根据Client ID 、Client Secret 和 code 可获得 token
根据 token 获得用户信息
必要的URL:
登录页面授权URL:
https://github.com/login/oauth/authorize?client_id=%s&redirect_uri=%s&state=%s
获得Token的URL:
https://github.com/login/oauth/access_token?client_id=%s&client_secret=%s&code=%s&redirect_uri=%s&state=%s
获得用户信息的URL:
https://api.github.com/user?access_token=%s
应用获得用户的信息时,会返回一个唯一的标识,用于唯一标识资源所有者即用户,于是我们可以将此标识与数据库中我们自己的本地用户相关联。
测试
在进行编码之前,我们首先访问上面的几种URL,并分析流程及返回结果。
首先访问https://github.com/login/oauth/authorize?client_id=50d7f61132da7f8574a1&redirect_uri=http://localhost:8080/oauth/github/callback&state=thisisrandomstring
分析:该URL为引导用户对应用授权github信息,参数client_id为该应用创建时的Client ID,redirect_uri为该应用创建时填写的Authorization callback URL,state为随机字符串,它用于防止跨站点请求伪造攻击。访问时结果如下:
响应结果能够理解,然后点击授权按钮,就会自动跳转到http://localhost:8080/oauth/github/callback?code=107b7d2f85201535880c&state=thisisrandomstring
,URL为我们填写的回调URL,code参数即为凭证,
state为上一步的随机字符串。
接下来,我们应该获取token,根据github官方文档,我们需要发起一个POST
请求,URL为https://github.com/login/oauth/access_token
,
需要携带的参数如下:
Name | Type | Description |
---|---|---|
client_id | string | Required. The client ID you received from GitHub for your GitHub App. |
client_secret | string | Required. The client secret you received from GitHub for your GitHub App. |
code | string | Required. The code you received as a response to Step 1. |
redirect_uri | string | The URL in your application where users are sent after authorization. |
state | string | The unguessable random string you provided in Step 1. |
接下来,我们通过Postman模拟这一个过程,结果如下:
您还可以根据Accept标头接收不同格式的内容:
Accept: application/json{"access_token":"e72e16c7e42f292c6912e7710c838347ae178b4a", "scope":"repo,gist", "token_type":"bearer"}Accept: application/xmlbearer repo,gist e72e16c7e42f292c6912e7710c838347ae178b4a
嗯,成功获取到了Token无误,接下来该获取用户的信息了。发起GET请求,URL为https://api.github.com/user
,携带参数access_token=获取到的token,结果如下,可以获取到用户的基本信息。
编码
首先需要一个service用来定义oauth的一些方法,如获取token,获取用户信息等。
package com.yunche.novels.service;import com.yunche.novels.vo.AuthUserVO;import org.springframework.util.MultiValueMap;/** * @author yunche * @date 2019/04/04 */public interface AuthService { String getToken(MultiValueMap
params); AuthUserVO getUserInfo(String token); boolean checkIsExistsOpenId(String openId); boolean storeOpenIdByUser(String openId, Integer userId); String getUserNameByOpenId(String openId);} 接着,使用GitHub来完成具体的service的实现。
package com.yunche.novels.service.impl;import com.yunche.novels.mapper.AuthForGitHubMapper;import com.yunche.novels.service.AuthService;import com.yunche.novels.util.AuthHelper;import com.yunche.novels.vo.AuthTokenVO;import com.yunche.novels.vo.AuthUserVO;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.stereotype.Service;import org.springframework.util.LinkedMultiValueMap;import org.springframework.util.MultiValueMap;import java.sql.Timestamp;import java.util.Date;import java.util.HashMap;import java.util.Map;/** * @author yunche * @date 2019/04/04 */@Servicepublic class GitHubAuthServiceImpl implements AuthService { @Autowired private AuthForGitHubMapper gitHubMapper; private static final String GET_TOKEN_URL = "https://github.com/login/oauth/access_token"; private static final String GET_USER_URL = "https://api.github.com/user"; private static final String CLIENT_ID = "50d7f61132da7f8574a1"; private static final String CLIENT_SECRET = "6779d154cfc44115e1f3607c0000085c5c1cf178"; private static final String REDIRECT_URI = "http://localhost:8080/oauth/github/callback"; @Override public String getToken(MultiValueMap
params) { params.add("client_id", CLIENT_ID); params.add("client_secret", CLIENT_SECRET); params.add("redirect_uri", REDIRECT_URI); AuthTokenVO authTokenVO = AuthHelper.sendPostGetToken(GET_TOKEN_URL, params); String token = authTokenVO.getAccess_token(); return token; } @Override public AuthUserVO getUserInfo(String token) { Map map = new HashMap<>(); map.put("access_token", token); return AuthHelper.sendGetToUser(GET_USER_URL, map); } @Override public boolean checkIsExistsOpenId(String openId) { return gitHubMapper.checkIsExists(openId) > 0; } @Override public boolean storeOpenIdByUser(String openId, Integer userId) { Date date = new Date(); Timestamp timeStamp = new Timestamp(date.getTime()); return gitHubMapper.storeOpenIdByUser(openId, userId, timeStamp) > 0; } @Override public String getUserNameByOpenId(String openId) { return gitHubMapper.getUserNameByOpenId(openId); }} 将需要获取的token和用户信息的json封装成对象。
package com.yunche.novels.vo;/** * @author yunche * @date 2019/04/04 */public class AuthTokenVO { private String access_token; private String token_type; private String scope; public String getAccess_token() { return access_token; } public void setAccess_token(String access_token) { this.access_token = access_token; } public String getToken_type() { return token_type; } public void setToken_type(String token_type) { this.token_type = token_type; } public String getScope() { return scope; } public void setScope(String scope) { this.scope = scope; } public AuthTokenVO() { } public AuthTokenVO(String access_token, String token_type, String scope) { this.access_token = access_token; this.token_type = token_type; this.scope = scope; }}
package com.yunche.novels.vo;/** * @author yunche * @date 2019/04/04 */public class AuthUserVO { /** * 用户第三方应用名 */ private String login; /** * 用户第三方唯一标识 */ private String id; /** * 用户第三方头像 */ private String avatar_url; public String getLogin() { return login; } public void setLogin(String login) { this.login = login; } public String getId() { return id; } public void setId(String id) { this.id = id; } public String getAvatar_url() { return avatar_url; } public void setAvatar_url(String avatar_url) { this.avatar_url = avatar_url; }}
mapper类操作数据库。
package com.yunche.novels.mapper;import org.apache.ibatis.annotations.*;import java.util.Date;/** * @author yunche * @date 2019/04/05 */@Mapperpublic interface AuthForGitHubMapper { /** * 检查该openId是否已经注册过 * @param openId * @return */ @Select("SELECT COUNT(*) FROM oauth_detail WHERE open_id=#{openId} and app_type='github'") Integer checkIsExists(String openId); /** * 存储该OpenId * @param openId * @param userId * @return */ @Insert("INSERT INTO oauth_detail(open_id, app_type, user_id, status, create_time) VALUES(#{openId},'github',#{userId},1,#{createTime})") Integer storeOpenIdByUser(@Param(value = "openId") String openId, @Param(value = "userId") Integer userId, @Param(value = "createTime") Date createTime); @Select("SELECT user_name FROM user, oauth_detail WHERE user_id=user.id AND open_id = #{openId}") String getUserNameByOpenId(String openId);}
package com.yunche.novels.mapper;import com.yunche.novels.bean.User;import org.apache.ibatis.annotations.*;/** * @author yunche * @date 2019/04/05 */@Mapperpublic interface UserMapper { @Insert("INSERT INTO user(user_name, password) VALUES(#{userName}, #{password}) ") @Options(useGeneratedKeys = true, keyProperty = "id", keyColumn = "id") Integer storeUser(User user); @Select("SELECT COUNT(*) FROM user where user_name=#{name}") Integer checkUserNameIsExists(String name);}
Controller类。
package com.yunche.novels.controller;import com.yunche.novels.bean.User;import com.yunche.novels.service.UserService;import com.yunche.novels.service.impl.GitHubAuthServiceImpl;import com.yunche.novels.util.MD5Utils;import com.yunche.novels.util.StringHelper;import com.yunche.novels.vo.AuthUserVO;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.stereotype.Controller;import org.springframework.util.LinkedMultiValueMap;import org.springframework.util.MultiValueMap;import org.springframework.web.bind.annotation.GetMapping;import org.springframework.web.bind.annotation.RequestParam;import org.springframework.web.bind.annotation.ResponseBody;import javax.servlet.http.HttpSession;/** * @author yunche * @date 2019/04/04 */@Controllerpublic class AuthController { @Autowired private GitHubAuthServiceImpl authService; @Autowired private UserService userService; @GetMapping("/oauth/github/callback") public String authorizeForGitHub(@RequestParam("code") String code, @RequestParam("state") String state, HttpSession session) { MultiValueMap
map = new LinkedMultiValueMap<>(); map.add("code", code); map.add("state", state); String token = authService.getToken(map); //获取用户在第三方的信息 AuthUserVO userVO = authService.getUserInfo(token); String openId = userVO.getId(); //注册该openId if(!authService.checkIsExistsOpenId(openId)) { User u = new User(); String userName = userVO.getLogin(); //确保用户的用户名唯一 while (userService.IsExistsName(userName)) { userName += StringHelper.getRandomString(3); } u.setUserName(userName); //生成一个随机的一定长度的字符串并使用MD5加密,由于第三方的密码不可用,故随机。 u.setPassword(MD5Utils.getMD5(StringHelper.getRandomString(16))); //注册用户 if(userService.insertUser(u)) { //将本地用户与OpenId相关联 if(authService.storeOpenIdByUser(openId, u.getId())) { //存储用户session session.setAttribute("user", u.getUserName()); } } } else { session.setAttribute("user", authService.getUserNameByOpenId(openId)); } // 重定向到之前需要授权的页面 return "redirect:" + state; }}
